The AN/PRC-117 Multiband Manpack Radio, or Multiband Multi Mission Radio (MBMMR), is a man-portable, tactical software-definedcombat-net radio, manufactured by Harris Corporation, in two different version:

• Version F (Foxtrot), namely AN/PRC-117F-MP Falcon II series, covering the 30-512 MHz frequency range, provided without internal GPS (optionally an external commercial GPS can be connected, or a GPS SAASM as a Precision Lightweight GPS Receiver [PLGR] or a Defense Advanced GPS Receiver [DAGR]);^[1]
• Version G (Golf), namely AN/PRC-117G-MP Falcon III series, covering the 30-2000 MHz frequency range, and provided with internal SAASM GPS (optionally an external commercial GPS can be connected).^[2]

Both radios have NSA certification for the transmission of voice and data traffic up to the Top Secret level.^[3]

The designation AN/PRC translates to 'Army Navy / Portable Radio Communications' used for two way Communications, according to Joint Electronics Type Designation System guidelines. The radios are also provided in a vehicular configuration under the AN/VRC-103 nomenclature.

Users[edit]

The AN/PRC-117F/G radio is currently in use with the United States NavySeabee and EOD teams in their MRAP and JERRV vehicles.^[1] The radio is also in use by the United States Marine Corps,^[4]United States Army,^[5]USSOCOM,^[6] United States Coast Guard, United States Air Force,^[7]Royal Air Force,^[8] Dutch Army, Spanish Air Force, British Army, Norwegian Armed Forces, Danish Army, Croatian Army^[9]Canadian Forces in Afghanistan and German Armed Forces.^[10]

The radio is part of an Over-the-horizon Satellite Communications and Improved Dual Command and Control Console system recognized by the US Army as a Top 10 Invention in 2005.^[11]

The radio has also been embedded in remote mine hunting systems for the US Navy.^[12]

Specifications[edit]

General[edit]

• Frequency Range: 30 MHz to 2 GHz
• Presets: 100 (110 including DAMA)
• Transmission Modes: FM, AM, PSK, CPM
• Tuning Resolution: 10 Hz
• Model: RT-1796 (P)(C)/U

Transmitter[edit]

• Output Power: 1 W to 20 W (Max)
• Harmonic Suppression: –40 dBc
• Frequency Stability: +/- 1.0 ppm

Receiver[edit]

• FM Sensitivity -118 dBm (10 dB SINAD)
• Adjacent Channel Rejection 60 dB

Interoperability[edit]

• Fill devices: AN/CYZ-10 DTD, AN/PYQ-10 SKL (Supports DS-101, DS-102 and Mode 2/3)
• Crypto Modes KY-57, ANDVT/KYV-5, KG-84C, FASCINATOR
• Radios
  • AN/PRC-119A/B/G
  • Other versions of the AN/PRC-117

Interfaces[edit]

• External Data: RS-232, MIL-STD-188-114A
• Remote control: RS-232, RS-422
• Antenna ports: Separate VHF, VHF-HI/UHF
• Audio: Six-pin Standard
• Power: Two BA-5590, BB-390A/U, BB-2590, or BB-590 batteries

Physical Dimensions[edit]

• 3.7H x 7.4W x 8.8D in. (w/o battery case)
• Weight 8.2 lbs (without batteries)

12 lbs with batteries

Environmental[edit]

• Temperature: -40 °C to 70 °C
• Immersion: 1 Meter
• Test Method: MIL-STD-810E
• Finish: CARCGreen

Key Features[edit]

• Removable keypad display unit
• Full numeric keypad
• NVG compatible display
• External GPS - DAGR, PLGR, and NMEA 0183 compatible

Rt 1796 Harris Tm

Waveforms[edit]

Line of Sight[edit]

• VHF/UHFAM/FM
• HAVE QUICK II ECCM
• ANW2 - Advanced Networking Wideband Waveform (Harris)
• SRW Soldier Radio Waveform ^[13]
• NATO SATURN waveform, per NATO STANAG 4372 - optional ^[13]

SATCOM[edit]

Harris Rt 1796 Manual Pdf

• MIL-STD-188-181-B/C
• MIL-STD-188-182-A
• MIL-STD-188-183-A/B
• High performance waveform (HPW) optional
• Mobile User Objective System (MUOS) - optional^[13]
